Renesas瑞薩MCU微控制器RL78/G22

發布時間：2024-05-14 09:31:07 瀏覽：589

　　Renesas MCU微控制器RL78/G22具有以下特點：

　　1. 低功耗：在CPU工作時的電流消耗為37.5μA/MHz，在STOP模式下為200nA。

　　2. 豐富的電容觸摸通道。

　　3. 完備的16-48引腳封裝和32KB-64KB閃存，展開了新一代RL78通用微控制器的產品線。

　　4. 最大工作頻率為32MHz，廣泛的工作電壓范圍為1.6V-5.5V。

　　5. 增強的模擬和安全功能以及SNOOZE模式可編程控制器可大幅降低間歇工作的功耗。

　　6. 提供豐富的開發環境，包括評估板(Fast Prototyping Board)和智能配置器(Smart Configurator)。

　　7. 兼容現有的RL78系列，適用于家電、消費類電子產品到工業設備的廣泛用途。

　　具體技術參數包括：

　　- CPU型號：RL78核心，最高32MHz

　　- 工作電壓范圍：1.6V至5.5V

　　- 封裝類型：16引腳至48引腳

　　- 閃存容量：程序閃存：32-64KB，SRAM 4KB，數據閃存2KB

　　- 工作溫度范圍：可達105°C

　　- 增強型電容式感應單元(CTSU2L)

　　- 定時器：8路16位定時器、1路看門狗定時器、1路32位間隔定時器

　　- PWM輸出：7路PWM輸出

　　- 模擬功能：10路10位A/D轉換器

　　- 片上振蕩器頻率(MHz)：高速：最高32MHz，中速：最高4MHz，低速：32.768kHz

　　- 貪睡模式排序器

　　- 事件鏈路控制器

　　- 其他功能：RTC、上電復位、低電壓檢測

　　- 封裝類型：SSOP、LQFP、HWQFN、WFLGA

產品型號：

Product ID	程序存儲器（KB）	內存（KB）	溫度范圍	數據閃存（KB）	I/O 端口	模數轉換器	產品尺寸
R7F102G4C3CNP#AA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C3CNP#BA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C3CNP#HA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#AA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#BA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#HA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#AA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#BA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#HA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#AA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#BA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#HA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G6C3CSP#CA0	32	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C3CSP#HA0	32	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C2DSP#CA0	32	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C2DSP#HA0	32	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E3CSP#CA0	64	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E3CSP#HA0	64	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E2DSP#CA0	64	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E2DSP#HA0	64	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G7C3CNP#AA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C3CNP#BA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C3CNP#HA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#AA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#BA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#HA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#AA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#BA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#HA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#AA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#BA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#HA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G8C3CLA#AC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C3CLA#BC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C3CLA#HC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#AC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#BC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#HC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#AC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#BC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#HC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#AC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#BC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#HC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102GAC3CSP#AA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC3CSP#BA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC3CSP#HA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#AA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#BA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#HA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#AA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#BA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#HA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#AA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#BA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#HA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GBC3CNP#AA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CNP#BA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CNP#HA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#AA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#BA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#HA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#AA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#BA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#HA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#AA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#BA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#HA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CFP#AA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC3CFP#BA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC3CFP#HA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#AA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#BA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#HA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#AA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#BA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#HA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#AA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#BA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#HA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GCC3CLA#BC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC3CLA#AC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC3CLA#HC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#BC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#AC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#HC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#BC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#AC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#HC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#BC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#AC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#HC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GEC3CNP#AA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC3CNP#BA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC3CNP#HA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#AA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#BA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#HA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#AA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#BA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#HA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#AA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#BA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#HA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GFC3CFP#AA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC3CFP#BA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC3CFP#HA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#AA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#BA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#HA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#AA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#BA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#HA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#AA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#BA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#HA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GGC3CFB#AA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CFB#BA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CFB#HA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#AA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#BA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#HA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#AA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#BA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#HA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#AA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#BA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#HA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CNP#AA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC3CNP#BA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC3CNP#HA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#AA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#BA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#HA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#AA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#BA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#HA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#AA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#BA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#HA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
